Precision-Machined Rigid Support for Board Protection
Support Plates are precision-machined fixtures engineered to provide rigid, stable support beneath the printed circuit board during press fit assembly. Designed to accurately support connector insertion forces, these tooling plates protect both the PCB and components from damage while improving setup efficiency and production throughput. Available in application-specific or universal configurations, Pentagon EMS Support Plates deliver reliable, repeatable performance for both prototype and high-volume manufacturing.
Reduces tooling costs by eliminating the need for individual bottom-side tools
Minimizes setup time for faster production changeovers
Increases manufacturing throughput and process efficiency
Reduces the risk of PCB and component damage during press fit operations
Provides rigid, repeatable support for accurate connector insertion
Improves consistency across prototype and production builds
Available with universal designs for greater manufacturing flexibility
Every project at Pentagon-EMS (StenTech) is custom-engineered to your exact requirements. Because no two projects are alike, our streamlined quote process helps move you from concept to production quickly, accurately, and with confidence.
