Wave Solder Pallets, SMT Process Carriers, Conformal Coat Fixtures, Press Fit Support Fixtures.... Pentagon EMS designs and manufactures tooling and fixtures to streamline and improve every aspect of the Printed Circuit Board assembly process.
Our Precision Machining group is also available to custom manufacture and assemble to your print specifications, from prototype to high volume production quantities.

Pentagon EMS combines Manufacturing Engineering, an experienced and innovative design group, and the latest CNC machining technology to create the kind of Value-Added supplier you need in your corner.  We partner with our customers, building lasting relationships, to consistently provide solutions for all of their printed circuit board assembly needs.

As you look through our website, you will find that we offer a wide variety of products for every process, from PCB assembly through inspection and test operations.

Read our Usability Guarantee and then give us a call and find out what makes us different.



WHAT OUR CUSTOMERS ARE SAYING



"You guys are truly amazing. Thanx for the great support & efforts! "



"Hey,
This aluminum bar is a clamping/glueing trimming aide for this phenolic/rubber assembly. Notice the incredibly perfect fit on this thing. Once again I appreciate Pentagon’s incredible skill, execution and service. THIS THING IS PERFECT!
Please share with your manufacturing people, etc. Notice the excellent deburring…."



"I want to let you know how great job you did for first two screen printer support plates. We checked fit and functions of plates with boards and machines, and got some feedbacks from our tech's, operators and our mgt. They are flawless."



"Hi guys, we don't often provide feedback on the many good fixtures that you have made for us, but wanted to let you know that this fixture worked perfectly on our selective solder machine. This fixture has allowed us to streamline our process, eliminate a lot of hand soldering and a special washing process."



"Thank you for getting this second fixture shipped. I received the first one and it looks great. As a matter of fact it was shown to the head of Design Engineering and they should be calling you to quote on some type of vibration fixturing. Keep up the Great work!!!"



"Out of all of the external companies/suppliers I have dealt with, none have been easier to work with than Pentagon EMS. Pentagon has proven to be a shining example in areas such as customer service, punctuality, and overall quality of products that other organizations should strive to achieve."



"Fantastic job on the fixture guys. Thank you guys again for expediting it and getting it to us on time."



"Thank you all for the superb turn around for these fixtures! Quite impressive!"



"I love you guys.
Thank you for getting these 10 fixtures today.
Please let your people know how much I appreciate your effort and dedication for custom-tools you are designing and making for your customers.
You are definitely better than Washington DC Pentagon."



"Great job, be sure to say thanks to your team. You pulled it out for me and I really appreciate it. Folks here are impressed and I think you'll get steady biz from us. Talk to you tomorrow."



"Success! We had the fixture in our hands right before lunch and we put it to work. It ran beautifully, 32 boards and a 3.1% MDR with the error being a lifted part. Barrel fill on the two capacitors was between 90 and 100% on all boards. Please pass this job well done to everyone who helped in making this happen. Thank you!"



"Thank you. You guys are very fast and I really appreciate this. Pentagon EMS was in my opinion a good choice. Fast – Solid - Perfect!"



"Great Job on the SMT fixture. Just wanted to let you know, this fixture worked very well. The design was well thought out which made it easy for the operators to install them in the carrier fixture. Our customer came by today to do a source inspection and commented on how well the edge connectors were soldered. We showed him the fixture and he was impressed. Thank you for the good work."



“Reliable service, good communication, strong and knowledgeable technical staff. A partner in solving our problems. Keep up the good work!"



“Personal attention to each and every order, on time delivery and great customer service are why you are the supplier of choice."



“I would definitely recommend Pentagon EMS as an approved vendor for all of (our) sites in the America’s. Having found someone this good, I would be hesitant to try another vendor at this point in time.”



“Thanks for your support. Your customer service is world class.”
